Red Cap

These premium distributors include authentic Chevrolet Performance melonized steel gears (USA), which are required on all Chevrolet Performance crate engines, or serious damage will occur. Validated harness and capacitor for reliable energy flow, Adjustable vacuum advance for fine tuning the rate and amount of advance that will result in increased power and eliminate harmful detonation, High-performance module: engineered with low saturation for maximum spark intensity, Bronze bushings precisely installed and line- honed for perfect positioning, Durable, centerless ground coated shaft for reliable energy transfer and long-term, trouble-free performance. FINAL ASSEMBLY, AND INDIVIDUAL INSPECTION IN WARREN, MICHIGAN.

Attributes:

• Brand Name: Proform
• GTIN: 00037995816835
• Advance Type: Mechanical and Vacuum
• Applications: Chevy V8 Engines
• Cap Color: Red
• Coil Wire Included: Yes
• Connector Type: Sealed
• Distributor Cap Included: Yes
• Emblem: Chevrolet Performance Logo
• Feature/Benefit: Includes a Chevrolet Performance melonized steel gear, which are inchrequired on all Chevrolet Performance crate engines, or serious damage will occur. inch
• Gear Material: Melonized Steel
• Grade Type: Performance
• Ignition Box Required: No
• Ignition Coil Included: Yes
• Ignition Rotor Included: Yes
• Length: 15
• Make: Chevrolet
• Marine Approved: No
• Mechanical Advance: 22 Degrees
• Number of Cylinders: 8
• Rotation: Standard
• Rotor Rotation: Clockwise (Right)
• Shaft Length: 9.65
• Shaft Material: Aluminum
• Terminal Gender: Male
• Terminal Quantity: 8
• Terminal Type: Lead Wire
• Trigger Type: Magnetic
• Vacuum Advance: Adjustable

Extended Information:

• Country of Origin: CN
• Emissions : Racing or Pre-Emissions Use Only

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Weight: 0 POUNDS
