Kleinn Model 2121 Sealed Pressure Switch - On: 90 PSI - Off: 120 PSI

The Kleinn Model 2121 is a premium sealed pressure switch engineered to automate your onboard air system by keeping tank pressure regulated between 90 PSI and 120 PSI. Optimized for use with the 6260RC air compressor, this heavy-duty switch features a standard 5% PSI variance tolerance and operates on 12-volt ignition power to signal a required SPDT 30-amp relay (Kleinn Model 340), safely turning the compressor on and off automatically. For maximum system protection, it is highly recommended to pair this switch with a 145 PSI safety relief valve (SKU 52145) installed on the air tank; in the event of a pressure switch failure, the safety valve will release a burst of air to alert you to cut power to the compressor, preventing a costly burn-out until the switch can be replaced.

• On: 90 PSI - Off: 120 PSI
• Note: 5% tolerance standard
• The use of a relay is recommended (Kleinn model 340)
• 20 amp max load
• Sealed 1/4" NPT Pressure Switch

Vehicle Specific

• Universal

Attributes:

• Brand Name: Kleinn Automotive Accessories
• GTIN: 00819147010908
• Add-On: Use a 145 PSI Safety relief valve with this, SKU 52145.
• Attribute 1: On: 90 PSI
• Attribute 2: Off: 120 PSI
• Attribute 3: Note: 5% tolerance standard
• Attribute 4: The use of a relay is recommended
• Attribute 5: 20 amp max load

Extended Information:

• Country of Origin: China
• Emissions : CARB Eligible

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 7 x 3 x 2 inches
• Weight: 0.2 POUNDS
