Super Victor GM LS7 Intake Manifold EFI 4150 Flange

Edelbrock part #28875 Super Victor LS7 intake manifold is designed for Gen IV LS engines equipped with LS7 cylinder heads or Edelbrock Pro-Port Victor Jr. cylinder heads. This manifold is .75" taller than our LS3 Super Victor intakes. The new Super Victor intake manifold is capable of airflow demands of 750+ hp on naturally aspirated engines. This manifold includes machined fuel injector bosses. A carburetor mounted style throttle bracket is recommended. Vehicle Specific

• Chevrolet:Small-Block Gen IV LS7:427 (7.0L)

Attributes:

• Brand Name: Edelbrock
• GTIN: 00085347288755
• Basic Operating RPM Range: 3500-8000
• CNC Ported: No
• Center Maximum Height: 8.420
• EGR Port: No
• Finish: Satin
• Flange Type: 4150
• Front Maximum Height: 8.420
• Gasket Or Seal Included: No
• Grade Type: Performance
• Material: Aluminum
• RGL: WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
• Rear Maximum Height: 8.420
• Series: Victor
• Single Or Dual Plane Type: Single
• Vehicle Model: Chevrolet

Extended Information:

• Country of Origin: US
• Emissions : Racing or Pre-Emissions Use Only

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 23.5 x 14.75 x 12 inches
• Weight: 20.1 POUNDS
