Mcleod Racing Flywheel Heat Shields

McLeod Racing Replacement Flywheel Friction Plates are constructed of incredibly strong A36 high carbon steel to deliver superior longevity and disc engagement. Each friction plate is heat-treated and meets high specifications for performance output. With McLeod Racing replacement flywheel heat shields, there is no need to resurface or replace the entire flywheel when changing or replacing the clutch, saving both time and money.

• The McLeod Racing removable heat shield allows users to replace the steel drive surface in the flywheel for a new drive surface when installing a new clutch system.

Attributes:

• Brand Name: McLeod
• GTIN: 00887753314116
• Flywheel Insert Inside Diameter (in.): 6.250
• Flywheel Insert Material: A36 Steel
• Flywheel Insert Outside Diameter (in.): 10.500
• Flywheel Insert Thickness (in.): 0.140
• Mounting Hole Pattern: 18 Hole
• Quantity: Sold individually.

Extended Information:

• Country of Origin: US
• Emissions : CARB Eligible

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 12 x 13 x 2 inches
• Weight: 2 POUNDS
