Float Set For Edelbrock VRS-4150 Race And Performance Series Carburetors

The Edelbrock #140536 Performer series 600 CFM manual choke Black Powder Coated carburetor is custom tuned to deliver the best performance possible with the Enforcer supercharger. Front and rear carbs sold separately. The Edelbrock #140536 is similar to a 1405, but is tuned specifically for use with the SBC TVS2300 Dual Quad Superchargers. The Edelbrock #140536 is for the front carburetor only. The rear carburetor must be used in conjunction with the front carburetor Edelbrock #140535. Several characteristics make the #140536 Performer Series 600 CFM manual choke Black Powder Coated carburetor an outstanding street performer. The first one is that metering rods are utilized to transition between circuits. The carburetor is unaffected by engine backfires, which means that there are no power valves to blow out, and the rods can be changed in seconds without carburetor removal or fuel draining. Secondly, the carburetor has the unique ability to "hold a tune", so once it is tuned, the carburetor stay's tuned. What this means to you is that compared to other carburetors, the performance remains consistent and the calibration stays unchanged. The lightweight all-aluminum body features a two-piece body that resists warping and is compatible with gasohol and blended fuels. The simple tub-type bowls and rear-pivot floats all contribute to a carburetor that's reliable, user-friendly and is easily tunable for miles and miles of trouble-free operation.

Attributes:

• Brand Name: Edelbrock
• GTIN: 00085347998005
• Adjustable Float Level: No
• Air Cleaner Flange Diameter: 5.125
• Barrel Quantity: 4
• Base Length: 6.25
• Base Width: 5.937
• Body Height: 3.25
• Body Material: Aluminum
• Center Hung Floats: No
• Choke Type: Manual
• EGR Port: No
• Finish: Black Powder Coated
• Flange Shape: Square Bore
• Float Drop: 1.0
• Float Level: 0.437
• Float Material: Brass
• Gasket Or Seal Included: Yes
• Grade Type: Performance
• Inlet Fitting Thread Diameter: 0.625
• Linkage Attached: No
• Main Venturi Diameter: 1.190
• Marine Approved: No
• Maximum Flow Rating: 600
• Metering Rod Length: 3.15
• Metering Rod Power Tip Diameter: 0.037
• Mounting Hardware Included: No
• Mounting Hole Diameter: 0.355
• Mounting Hole Quantity: 8
• Primary Jet Diameter: 0.100
• RGL: WARNING: This product can expose you to Zinc, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
• Secondary Jet Diameter: 0.107
• Small Venturi Diameter: 1.560
• Spacer Included: No
• Street Legal: No

Extended Information:

• Country of Origin: US
• Emissions : EPA Eligible
• Life Cycle Status: Obsolete

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 13.25 x 7.375 x 6.75 inches
• Weight: 9.1 POUNDS
