ECF-1: (FUEL) Ethanol Advanced Gauge Complete Kit

The Ethanol Advanced Gauges Combine Innovate Motorsports Patented Directdigital O2 Sensor Control Technology With Application Specific Sensors, An Oled Display, And A Sophisticated Ethanol Content Sensor That Also Measures Fuel Temperature. These Capabilities Allow The User To Monitor And Capture Critical Metrics For Accurate And Reliable Tuning While Operating With High Ethanol Content Fuel. The Ethanol Advanced Gauges Offer The Looks, Safety And Performance Enthusiasts Demand! Includes Innovate Mts Serial Comms For Use With Mts Enabled Devices To Add Additional Logging Channels For Analysis With Powerful Logworks Pc Software.

• Four-in-one, ethanol content percentage, fuel temperature, fuel pressure, and wideband air/fuel ratio gauge
• OLED user configurable display (one, two, or four channel viewing modes)
• Warning indicator LED for low fuel pressure (user programmable)
• 0-145 PSI (10 Bar) fuel pressure sensor
• 4-Configurable Analog Outputs For Use With Standalone And Other Programmable Ecus As Well As External Data Loggers
• 52mm (2 1/6) diameter gauge body with interchangeable faceplates and bezels: Black and silver bezel, black and white faceplates included
• No PC required for configuration
• Bosch LSU 4.9 wideband O2 sensor
• Patented DirectDigital wideband sensor control, 100% digital wideband air/fuel ratio technology!
• Wideband O2 Compatible with several fuel types (Leaded, Unleaded, Diesel, E85 & more)

Attributes:

• Brand Name: Innovate Motorsports
• GTIN:
• Bezel Color: BLACK OR SILVER
• Bezel Style: Innovate
• Cup/Hole Size - Metric - CM: 5.2
• Cup/Hole Size - Standard - IN: 2.0625 in.
• Dial Color: BLACK OR WHITE
• Gauge Type: Multi Gauge - ETHANOL %, FUELP, FUELT, AFR
• Included Wire Harness: 3887, 3840
• Includes Adapter/Fitting: 3839
• Includes Sensor Unit: 3888
• Lens Style: Flat, Clear
• Lighting Color: WHITE
• Lighting Type: OLED
• Movement: Digital
• Outer Bezel Diameter - Standard: 2.44
• Product Overall Depth: 2.4
• Product Overall Height: 2.44
• Product Overall Width: 2.44
• Product Type: Gauge Ethanol Content / Fuel Temp
• Range: 0 - 145 PSI (10 BAR) / 0 - 100% / -40 - 257 F (-40 - 125Celsius) / 7.4:1 - 22.4:1 AFR (0.5 - 1.5 LAMBDA)
• Related Item: 77020
• Size - Metric - CM: 5.2
• Size - Standard - IN: 2.0625 in.
• Upsell: 3906

Extended Information:

• Country of Origin: US
• Emissions : CARB Eligible
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Weight: 0 POUNDS
