DEI 10390 Reflect-A-GOLD Heat Reflective Roll 24" X 150' 010390

Reflect-A-GOLD(TM) solves the problem of heat soak into air boxes, seats, firewalls, transmission tunnels and intakes. Reflect-A-GOLD is an adhesive heat shield made from a metalized polyimide laminated to a light weight glass fiber cloth with a high temperature pressure sensitive adhesive for use in extreme temperature swing environments. Our lightweight, adhesive thermal shielding is easily applied and won't lift off. It's minimal clearance and ease of use makes Reflect-A-GOLD a highly effective material for firewalls, fuel cells, engine covers, under hoods, engine compartment, bulk heads, seat bottoms, and anything or area that needs protection from heat. For firewalls, bulkheads, engine covers, floors, seat bottoms & more Handles continuous temps up to 800F Resists UV degradation for long-term performance Adhesive protected by release liner rated up to 325F 0.0065 in. thick Easy to apply, won't lift off DO NOT apply directly to exhaust components.

• For Firewalls/Bulkheads/Engine Covers/Floors/Seat Bottoms
• Handles Continuous Temps Up To 800 Degrees F
• Resists UV Degradation For Long-Term Performance
• Adhesive Protected By Release Liner Rated Up To 325 Degrees F
• Virtually NO Clearance Needed
• Light Weight And Flexible-Trim To Size
• 0.0065 in. Thick
• Easy To Apply- Wont Lift Off

Attributes:

• Brand Name: Design Engineering
• GTIN: 00607078103901
• Adhesive Heat Resistance: 325°F
• Application Method: Stick
• Backing: Adhesive
• Color: Gold
• Fiber Reinforced: Yes
• Includes: One 24 inch by 150 foot roll of Reflect-A-Gold.
• Length: 150
• Material: Gold Polyimide over Glass Fiber Scrim
• Maximum Temperature Rating: 800
• Radiant Heat Resistance: 850°F
• Resistant To: Heat
• Thickness: .0625
• Width: 24

Extended Information:

• Country of Origin: United States
• Emissions : 4
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 6 x 6 x 24 inches
• Weight: 16.77 POUNDS
