BluePrint Engines Chrysler Small Block Compatible 408 C.I. Standard Edition - 727 Automatic Transmission - Polished Pulley Kit - Fuel Injected

BluePrint Engines 408 c.i. Chrysler Compatible Builder Series - Standard Edition - Fuel Injected - 727 Automatic Transmission - Polished Pulley Kit. Includes 30-Month / 50,000 Mile Warranty & Dyno Tested

• Standard Edition Chrysler Compatible Builder Series - EFI - Polished Kit

Attributes:

• Brand Name: BluePrint Engines
• GTIN: 00887753993700
• Air Cleaner Included: Yes
• Block Description: Hand Picked Seasoned Magnum Block - 2 Bolt Main - 4.040" Bore
• Cam: Hydraulic Roller - .544 Intake / .541 Exhaust Lift - 236 Intake / 242 Exhaust Duration -@.050-110 LSA
• Carb/Fuel Injection Included: Yes
• Compression Ratio: 10:1
• Crankshaft Vendor: BluePrint Engines
• Cylinder Head Vendor: Edelbrock Casting, Machined and Assembled by BluePrint
• Cylinder Heads: Aluminum Cylinder Heads
• Cylinder Heads Included: Yes
• Distributor Included: Yes
• Distributor Vendor: BluePrint Pro Billet
• Engine Balance: Externally Balanced
• Firing Order: 1,8,4,3,6,5,7,2
• Flexplate/Flywheel Included: Yes
• Fuel Delivery Type: Sniper II EFI
• Fuel Delivery Vendor: Holley
• Fuel Pump Included: Yes
• Harmonic Balancer Included: Yes
• Horsepower: 465
• Intake Manifold Included: Yes
• Intake Manifold Type: Dual Plane, Satin Aluminum
• Intake Manifold Vendor: Edelbrock or BluePrint Engines
• Oil Pan Included: Yes-Front Sump
• Pistons: Forged
• Pulley Kit Included: Yes - Polished - Water Pump, Type II Power Steering Pump, 140amp 1-wire Alternator, Peanut Style Air Conditioning Compressor.
• Quantity: EA
• Rear Main Seal Style: 2 Piece
• Recommended Flexplate/Flywheel: BPP727360
• Recommended Harmonic Balancer: BPP360
• Recommended Octane Fuel: 91+ Octane
• Recommended Spark Plug: BPP7938 NGK 7938 BKR5E
• Recommended Spark Plug Gap: .035 in.
• Recommended Stall Converter: 2200-2600 RPM
• Rotating Assembly: Cast Crank - 4.000 in. Stroke and 6.123 in. Rods
• Spark Plug Wires Included: Yes
• Spark Plugs Included: Yes
• Timing Cover Included: Yes
• Timing Requirements: Initial Timing 10-16 - Total Timing 32-34
• Torque: 494
• Transmission Model: 727
• Transmission Type: Automatic
• Valve Covers Included: Yes
• Water Pump Included: Yes

Extended Information:

• Country of Origin: US
• Emissions : Racing or Pre-Emissions Use Only

Packing Information:

• Quantity of Each: 1
• Package UOM: EA
• Dimension: 73 x 32 x 46 inches
• Weight: 935 POUNDS
