Bilstein Shock Absorbers

Bilstein AS3 Series shock absorbers are developed to deliver superior damping characteristics with virtually no rod pressure build-up. Based on Bilstein’s race-proven 46mm monotube design, the AS3’s unique piggyback nitrogen chamber delivers a fade-free performance without the gas pressure buildup that’s common in conventional shock designs. The aluminum threaded body modular assembly with single adjustable shaft tuning is purchased as a dry kit with pistons, piston bands and heims sold separately. The AS3 Series shock absorber offers consistent grip and optimal traction.

• Bilstein AS3 Series shock absorbers are developed to deliver superior damping characteristics with virtually no rod pressure build-up.
• Based on Bilstein’s race-proven 46mm monotube design, the AS3’s unique piggyback nitrogen chamber delivers a fade-free performance without the gas pressure buildup that’s common in conventional shock designs.
• The aluminum threaded body modular assembly with single adjustable shaft tuning is purchased as a dry kit with pistons, piston bands and heims sold separately.

Vehicle Specific

• No Applications

Attributes:

• Brand Name: Bilstein
• GTIN: 00651860916200
• Adjustable Damping: Single Adjustable - Rebound
• Body Design: Threaded Body Screw Top (Coilover)
• Body Material: Aluminum
• Collapsed Length (IN): 17.58
• Collapsed Length (MM): 446.5
• Extended Length (IN): 22.83
• Extended Length (MM): 580.0
• Finish: Clear Anodized
• Internal Design: Monotube
• Lower Mount Type: 1/2in Heim
• PartType: Shocks / Struts
• Piston Diameter: 46mm
• Piston Type: Sold Separately
• Segment: Motorsports
• Series: AS3 Series
• Shaft Diameter: 14mm
• Spring Hardware: E4-MSG-0096A00
• Spring Seat Included: Yes
• Stroke/Travel Length (IN): 5.45
• Stroke/Travel Length (mm): 138.4
• Upper Mount Type: 1/2in Heim
• Valving Identifier: Dry Kit (no valving)

Extended Information:

• Country of Origin: US
• Emissions : 4
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1.0
• Package UOM: EA
• Dimension: 26.7500 x 6.1000 x 6.1000 inches
• Weight: 7.0000 POUNDS
